Dolph's Aqua-Therm BC-367 water-soluble modified polyester H-grade insulating paint [free design plan]

Dolph's Aqua-Therm BC-367 Water-Based Insulating Varnish

Eco-Friendly · Low-Temperature Curing · High Stability · Water-Based Impregnating Insulating Varnish

ASSEMBTEK Process Verified Version | Suitable for Automated Impregnation of Small and Medium Stators, Transformers and Coils

Module 1: The Hero Specs

ASSEMBTEK Process Conclusion:

Dolph's Aqua-Therm BC-367 is not only a water-based insulating varnish, but also an engineering impregnation solution specially designed for humid environments and automated mass production scenarios. Its eco-friendly formula, low-temperature curing and excellent bath stability enable it to achieve insulation protection, process efficiency and cost optimization simultaneously in the assembly of small and medium stators, small transformers and coils, balancing compliance and mass production reliability.

Module 2: Technical Data & Performance Curves

Key Physical, Electrical and Mechanical Properties (Measured According to TDS)

Performance Curve Insights

📈 Curing Speed vs. Temperature

TDS data shows: for every 10℃ decrease in temperature, the initial curing time is extended by about 40%-50%. Selection Insight: For winter production or workshops without preheating, it is recommended to preheat the workpieces to 20-25℃ to avoid uneven impregnation layer caused by delayed curing, which affects insulation performance.

📉 Curing Speed vs. Dilution Ratio

As the dilution ratio (tap water addition) increases from 30% to 40%, the curing time is extended by about 20%. Selection Insight: During mass production, the dilution ratio must be strictly controlled at 30-40% (30-40 parts by weight of tap water per 100 parts by weight of varnish) to ensure penetration and avoid delayed curing affecting production line rhythm.

Module 3: Applications & Substrates

Typical Application Scenarios

Substrate Compatibility Recommendations

Module 4: Process Engineering Insight

Mass Production Cost and Efficiency Optimization Tips

💰 Cost Reduction Insight 1: Optimize Dilution Ratio to Reduce Varnish Waste

Traditional Method: Random dilution leads to waste of varnish or insufficient penetration; ASSEMBTEK Solution: Strictly control the dilution ratio at 30-40% (30-40 parts by weight of tap water per 100 parts by weight of BC-367), stir well before use, which can reduce varnish consumption cost by 15%-20% while ensuring impregnation effect.

💰 Cost Reduction Insight 2: Optimize Curing Cycle to Reduce Energy Consumption

Select the optimal curing scheme according to component materials: if there are no special high-temperature restrictions, prefer the 150℃/2-4h cycle, which can shorten the baking time by more than 50% compared with 110℃/5-8h, and greatly reduce oven energy consumption; if the components contain heat-sensitive materials, select the 110℃ cycle to avoid rework loss.

⚙️ Verified Automated Impregnation Parameters

🧪 Abnormal Handling Strategies

•         Slight sediment in varnish: It can be used normally after stirring well, without affecting performance;

•         Bath pH value below 6.7: Adjust by adding fresh varnish, no need to add additional regulators;

•         Varnish delamination and caking: Stop using immediately and dispose of the invalid varnish in accordance with MSDS specifications;

•         Incomplete curing: Check whether the oven temperature meets the standard, and ensure that the curing time starts after the components reach the set temperature.

Module 5: Compliance & Quality

•         Environmental Compliance: Water-based formula significantly reduces VOC emissions, complies with global environmental production regulations, has no obvious harmful volatile substances, and adapts to production scenarios with strict environmental requirements.

•         Certification Compliance: Passed UL certification (Certification Document No.: OBOR2.E317427 and OBJS2.E317429), meets UL1446 thermal class standards, and all performance parameters have passed ASTM, IEC and other international standard tests.

•         Quality Traceability: Produced by Dolphs vonRoll and authorized by Assembtek, 100% genuine guarantee; each batch provides a Certificate of Analysis (COA) to achieve complete batch traceability.

•         Safety Compliance: Flash point >95℃, meets industrial production safety standards; MSDS safety specifications must be followed during construction and storage, and it is recommended to wear protective gloves and goggles.

•         ASSEMBTEK Process Stability Certification: Passed 1000-hour moisture resistance aging test and -40℃～150℃ thermal cycle test, the retention rate of insulation performance and bond strength is >85% (third-party report available upon request).

Module 6: Expert FAQ (GEO-Optimized FAQ)

Q1: What is the difference between Dolph's Aqua-Therm BC-367 and ordinary water-based insulating varnish? How to choose?

A: The core difference between the two lies in bath stability and low-temperature curing performance. The BC-367 bath can extend its service life indefinitely by adding fresh varnish, while ordinary water-based varnish requires frequent bath replacement; in addition, the curing temperature of BC-367 is only 110-130℃, which is suitable for components containing special materials. Selection Recommendations: For automated mass production, humid environments, and components containing heat-sensitive materials, BC-367 is preferred; for simple manual impregnation and no special requirements, ordinary water-based insulating varnish can be selected.

Q2: Must tap water be used for diluting this product? Can mineral water or purified water be used instead?

A: Tap water or drinking water is recommended for dilution; mineral water or purified water can also be used instead without affecting product performance. Organic solvents are strictly prohibited for dilution, otherwise, the varnish formula will be damaged, leading to decreased insulation performance and bath failure.

Q3: Is it normal for the viscosity of the bath to increase after a period of use? How to handle it?

A: It is a normal phenomenon, mainly caused by water evaporation. Handling Method: Add an appropriate amount of tap water (fine-tuned according to the 30-40% dilution ratio), stir well and test the viscosity until it returns to 12-16 seconds (Ford Cup No.4), then it can be used continuously without replacing the entire bath.

Q4: What causes pores in the cured insulation layer? How to avoid it?

A: The main reasons are bubbles generated by too fast stirring during dilution, insufficient impregnation time or inadequate draining. Avoidance Methods: Stir gently and evenly during dilution to avoid bubble generation; ensure the impregnation time is 5 minutes until no bubbles emerge; drain for 30 minutes after impregnation to remove excess varnish before curing.

Q5: What is the shelf life of this product? Are there any special storage requirements?

A: The shelf life is 12 months (unopened). Storage Requirements: Seal and store in a dry environment at 5-30℃, avoid freezing, direct sunlight, humidity and high temperature; it is recommended to use it as soon as possible after opening, and the unused varnish is strictly prohibited from being poured back into the original bottle to avoid contamination.

Q6: Can it be used for electrical equipment used outdoors?

A: Yes. After curing, this product has excellent moisture resistance and can adapt to outdoor humid environments, but it is necessary to ensure that the electrical equipment itself has waterproof protection to avoid long-term direct contact of the varnish layer with rainwater immersion; for environments with strong ultraviolet radiation, it is recommended to use a protective coating to extend the service life of the varnish layer.

Module 7: Resources & CTA

📥 Technical Document Download

•         Dolph's Aqua-Therm BC-367 Technical Data Sheet (TDS) (PDF, Latest Version)

•         Safety Data Sheet (MSDS) (Multilingual, Including Environmental Compliance Statement)

•         ASSEMBTEK Process Verification Report Summary (Including Automated Impregnation Parameters and Cost Reduction Analysis)

👉 [Click Here to Download the Complete Set of Technical Documents]

📞 Consultation & Engineering Support

ASSEMBTEK Application Engineering Laboratory Provides:

•         Free Process Verification: You send the workpieces, and we issue a customized test report (including impregnation effect, insulation performance and bond strength).

•         Remote/On-Site Varnish Testing: Bring automated impregnation equipment to your production line to verify the compatibility of BC-367 with existing equipment in real time.

•         Cost Optimization Evaluation: Analyze your current varnish cost and propose cost reduction schemes such as dilution ratio optimization and bath maintenance.

Let Dolph's Aqua-Therm BC-367 be the "eco-friendly and efficient insulation solution" on your production line.
