Loctite 620 high strength and high temperature resistant retaining adhesive green
SKU: LT01173
- Regular price
- $35.70
- Sale price
- $35.70
- Regular price
-
Detailed product description
Product Introduction
LOCTITE 620 is designed for bonding cylindrical fittings, especially where bonding gaps approach 0.2 mm and where maximum strength is required at room temperature. The product cures without air between closely fitting metal surfaces and prevents loosening and leaking due to shock and vibration. LOCTITE 620 provides powerful curing properties. The product offers higher temperature performance, making it particularly suitable for components that maintain higher temperatures, such as dowel pins in radiator assemblies and bearings in automotive transmissions. Typical applications include locking bushings and sleeves to housings and shafts.
Product technical parameters
| Manufacturer | Loctite |
| Product model # | Loctite 620 |
| Manufacturer number | 135514 |
| Chemical composition | Methacrylate |
| Color appearance | Green |
| Component | Single component |
| Curing method | Anaerobic curing |
| Cure time | 60.0 minutes up to 72 hours |
| Dielectric strength | 31 kV/mm |
| Elongation | <1% @break |
| Flashpoint | >93.3°C |
| Gap filling | 0.25 mm |
| Using temperature | Up to 200 °C |
| Shear strength | 2,495 to 3,495 @ 22 °C |
| Proportion | 1.16 @ 25 °C |
| Thermal conductivity | 0.1 W/mK |
| Viscosity | 8000 cps @ 25 °C |
- Typical environmental resistance test results
- Chemical Resistance/Solvent Resistance Test Results
- Thermal aging test results
Spec // as published by the manufacturer
At a glance
- Product type
- Anaerobic
- Brand
- Loctite®
- Chemistry
- Acrylic Methacrylate
- Cure mechanism
- Thermal Curing
Substrates in scope
Declared by manufacturer
Values are as published by the manufacturer for this grade. They describe the product family, not a test report for your assembly — ask us for the current data sheet before you design against them.
